What are the features of centrifugal disc finishing machines?
Our centrifugal finishing machine combines high efficiency, safety, and versatility, specifically designed to meet the stringent demands of modern
manufacturing for precision surface finishing. Below is a detailed description of its core processing capabilities:
1.Multi-Functional Processing in One Unit
A single machine efficiently handles multiple processes including deburring, polishing, grinding, and chamfering plastic parts, streamlining workflows
and reducing equipment investment.
2.Timed Polishing: Safe and Convenient
Equipped with timed polishing functionality, the machine operates unattended once programmed. The entire process is straightforward, safe, and
convenient, eliminating operational risks.
3.Dry Polishing for Mirror Finish
Advanced dry polishing technology achieves the highest mirror brightness standards without liquid media, ideal for moisture-sensitive parts or those
requiring extreme gloss.
4.High-Efficiency Processing for Speed and Output
Optimized centrifugal flow design enables rapid polishing at speeds far exceeding traditional methods, meeting urgent demands for high efficiency
and production volume.
5.Automated Operation, One Operator for Multiple Machines
The entire process operates fully automatically without manual intervention. A single operator can effortlessly manage multiple units, significantly
reducing labor costs and boosting overall production efficiency.
6.Durable Core Components
Critical parts feature high-wear-resistant tungsten alloy gasket structures, greatly enhancing the equipment's abrasion resistance and impact tolerance.
This ensures long-term stable operation and extends the machine's service life.
7.Digital Intelligent Monitoring
Core parameters including voltage, current, frequency, and time are digitally monitored and displayed.
|
What Materials Can You Process with a Centrifugal Disc Finishing Machine?
A centrifugal disc finishing machine is engineered to deliver high-quality, damage-free surface finishing for a wide range of materials. Whether you are
working with delicate jewelry or precision metal components, this advanced polishing system ensures exceptional results. Below are some of the key
materials that can be effectively polished using this method.
1. Rings
From precious gold and silver bands to intricate designer rings, this machine offers a gentle yet efficient polishing solution. Its controlled
cyclonic action ensures that even the most delicate ring surfaces are smoothed and shined without risk of damage, making it ideal for
high-value jewelry finishing.
2. Amber Stones
Baltic amber beads and other amber pieces require careful polishing to reveal their natural luster. The centrifugal disc finishing machine provides
the consistent, non-abrasive action needed to enhance amber’s hidden beauty, resulting in a brilliant shine suitable for fine jewellery.
3. Watch Parts
Capable of handling materials commonly used in watchmaking—such as stainless steel, titanium, bronze, and ceramic—this machine delivers precise
smoothing, cleaning, and drying. It guarantees zero damage to sensitive components, ensuring that each part maintains its structural integrity while
achieving a flawless finish.
4. Pearls
Whether saltwater or freshwater, small to medium-sized pearl jewelry can be polished safely and effectively. The machine’s gentle tumbling
motion and adjustable pressure prevent surface scratches or nicks, preserving the pearl’s natural elegance while improving its shine.
5. Coins
Gold and silver coins demand careful handling to avoid wear or devaluation. Thanks to its precision operation, the centrifugal disc finishing machine
offers a non-destructive polishing process that enhances the coin’s appearance without compromising its detail or material quality.
6. Keys
7. Dental Parts
9. Belt Buckles
8. Electric Components
|
What models of centrifugal disc finishing
do we offer? We have 18L single barrel, double barrel, three barrel. 36L single barrel, double barrel, three barrel. We can provide you with product customization
services. We will try our best to make the color or special shape you prefer. If you have any special customization needs, please contact us.
| MODLE | Volume (L) | Power (KW) | Voltage (V) | Maximum Speed (r/min) | Outer Diameter (CM) | Weight (KG) |
| 18L SINGLE BUCKET | 18 | 0.75 | 220 | 500 | 70*90*140 | 140 |
| 18L DOUBLE BUCKET | 18X2 | 0.75X2 | 220 | 500 | 120*90*140 | 235 |
18L THREE BUCKET | 18X3 | 0.75X3 | 220 | 500 | 170*80*145 | 330 |
| 36L SINGLE BUCKET | 36 | 2.2 | 380 | 500 | 95*90*145 | 220 |
| 36L DOUBLE BUCKET | 36X2 | 2.2X2 | 380 | 500 | 150*90*145 | 370 |
| 36L THREE BUCKET | 36X3 | 2.2X3 | 380 | 500 | 215*82*145 | 530 |
| Compared to other finishing machines, what are the advantages of centrifugal vortex polishing machines?
Maximize your polishing efficiency and ROI with our advanced centrifugal disc finishing technology. Designed for superior performance, this machine delivers significant advantages over conventional finishing methods. Here are the top 7 benefits:
1. Significant Energy Savings
Experience reduced overall energy consumption thanks to the machine's high-efficiency motor and optimized cyclonic action, leading to lower operational costs.
2. Reduced Maintenance Costs
The robust design and efficient operation minimize wear and tear, resulting in lesser maintenance requirements and long-term cost savings.
3. Dramatically Increased Productivity
Achieve up to 10 times higher efficiency compared to traditional tumblers or vibratory finishers. Process more batches in less time, dramatically boosting
your output.
4.Superior Finish on Complex Parts
Perfect for delicate and intricate components. The machine delivers a high-quality, smooth finish on thin or complex workpieces without compromising detail.
5. Faster Cycle Times
Reduce processing time significantly. Achieve the desired mirror-like or satin finish much faster, accelerating your production timeline.
6. Zero-Damage Polishing
The gentle, controlled tumbling action ensures zero impact and zero damage to your parts, preserving critical dimensions and surface integrity.
7. High-Volume Processing Capability
Finish more materials in less time. Our machine offers a higher throughput within the same cycle time compared to other finishing equipment, maximizing
your capacity.
| What results can be achieved by using a centrifuge?
1. Rust removal and refurbishment
2. Deburring
3. Polishing and brightening
4. Deburring and chamfering
| Dry vs. Wet Finishing: Can the Machine Handle Both?
Quick Answer: Absolutely！ Our centrifugal disc finishing machine is engineered for versatile dry and wet processing, allowing you to choose the ideal method for
your specific application.
1. Dry Finishing: For a High-Gloss Polish
As the name suggests, the dry finishing process does not use water or other liquids. Instead, a specialized polishing compound or paste is applied to the tumbling media.
2. Wet Finishing: For Intensive Deburring and Cleaning
Wet finishing, on the other hand, utilizes a mixture of water and specialized compound chemicals during the operation. This solution helps to lubricate parts, reduce heat from friction, and carry away debris removed from the workpieces.
Our machine’s flexible design empowers you to switch between these methods seamlessly, ensuring you always get the perfect finish for your project.
| How to order centrifugal disc finishing machine?
Email：hznorden@gmail.com
Telephone: +86 13625726381
WhatsApp：+86 13625726381
Website：https://www.nordenmachine.com/contactus.html
